Magnetic compounds
Magnetic and mechanical functions
intelligently combined
Application-specific magnetic compounds for efficient functional components
Max Baermann develops customized magnetic compounds for maximum geometric and magnetic design freedom in the production of functional components. Whether for robotics, automobiles, household appliances or technical pumps and motors, we match polymer binders and fillers precisely to the magnetic, mechanical and thermal properties your application requires – and can even provide heavy rare earth free solutions. We supply the custom magnetic compounds as ready-to-mold pellets or as near-net-shape components for sensors, rotors, actuators and other industrial applications. Discover the benefits of working with Max Baermann.
Polymer binders:
- polyamide 6 (PA6)
- polyamide 11 (PA11)
- polyamide 12 (PA12)
- polyphenylene sulfide (PPS)
Magnetic fillers:
- strontium ferrite (SrFe)
- neodymium iron boron (NdFeB)
- samarium cobalt (SmCo)
- samarium iron nitride (SmFeN)
Advantages
Magnetic compounds from Max Baermann make it possible to achieve …
mechanical and magnetic functions in a single production step
precise magnetic functional components – even with complex geometries
application-specific magnetization patterns with tight tolerances
multipole or locally adapted magnetic field profiles within the component
lower eddy current losses than solid sintered magnets*
independence from heavy rare earths and Chinese supply chains*
near-net-shape manufacturing (less finishing and fewer bonding/assembly processes)
low product carbon footprint compared with sintered magnets
*depending on the filler
Processing options and fields of application for magnetic compounds
Magnetic compounds from Max Baermann are the basis for efficient sensors, rotors and actuators in automotive technology, robotics, automations, consumer electronics, power tools, pumps and more. To achieve this, we first process our compounds into highly filled pellets using a co-kneader or twin-screw extruder, from which we then form near-net-shape components by injection molding. The magnetic function is thus integrated directly – there is no need to glue magnet blocks in afterwards.
Depending on the application, we produce magnets with our magnetic compounds directly as single-, two- or multi-component solutions
- as an insert solution for overmolding inserts such as shafts, bushings or metal cores, or
- as an overmolding solution applying an additional magnetic layer to existing components.
- As a single magnet for individual customer-specific in-house further processing by gluing or overmolding
Good to know: we also develop special compound formulations to obtain drinking water approval for your magnetic components and for applications with rapid temperature fluctuations.
Discover application examples of our magnetic compounds here:
Multipole encoder ring for precise speed detection at the wheel bearing or axle in vehicles and other mobile system applications
Component with multipole or coded, angle-accurate magnetization for absolute or incremental detection of the steering wheel position
Multipole ring, encoder or magnetized rotor surface for precise detection of rotating shafts or rotors during operation
Magnetic rotor for high-performance BLDC drives in drills, saws, grinders and other electric power tools
Magnetic rotor for auxiliary water, oil, fuel, coolant, recirculation, circulation, heating, thermal and filter pumps in operation
BLDC rotor for cooling and air conditioning in electric fans and blowers in vehicles, household appliances and industry
Position magnet for linear or rotary sensors for precise detection, control and adjustment of different valve positions
Small rotor or position magnets for actuators used to position air and blend flaps precisely in HVAC systems
Magnetic rotor drive with optional speed or position feedback for window regulators and the adjustment of individual seat axes
Discover how our innovative magnetic compounds free of heavy rare earths contribute to more resilient supply chains, greater resource efficiency and more sustainable products.
More compounds:
Contact us for further information
Would you like to have customized magnetic compounds developed for your application? We support you from material selection through to a production-ready component solution.
